釬焊板式換熱器3
釬焊板式換熱器的顯著特點
為廣大用戶節省了投資和運費提供了保證
1、結構緊湊，易安裝，使用薄板片隔熱系數高，滯液量少。
2、用水量少，釬焊式板式熱交換器換熱效率高。
3、污垢系數低，高湍流降低了污垢系數，從而減少了清洗次數。
4、重量輕，僅相當于管殼式換熱機的20%~30%。
5、經久耐用能承受高溫（250度）和高壓（45bar）清除了腐蝕問題，取消了墊片。
6、高品質多年來在傳熱領域的運行經驗和精確的計算機輔助設計，使寶得板式熱交換器
具有國內同行業領先水準。 產品廣泛應用于冶金、食品、輕工、化工、制冷和暖通等領域
釬焊換熱器產品規格
|
型號 |
P-14 |
P-20 |
P-18 |
P-26 |
P-30 |
P-50 |
|
寬A（mm） |
76 |
76 |
94 |
108 |
124 |
108 |
|
高B（mm） |
206 |
318 |
210 |
310 |
304 |
525 |
|
厚E（mm） |
9+2.3n |
9+2.2n |
9+2.3n |
10+2.3n |
13+2.3n |
10+2.35n |
|
水平接口中心距C |
42 |
42 |
52 |
50 |
70 |
50 |
|
垂直接口中心距D |
172 |
282 |
167 |
250 |
250 |
466 |
|
重量（kg） |
0.6+0.06n |
1.0+0.08n |
1.0+0.07n |
1.3+0.12n |
2.2+0.16n |
2.6+0.19n |
|
型號 |
P-95 |
P-120 |
P-180 |
P-190 |
P-200 |
P-600 |
|
寬A（mm） |
188 |
246 |
254 |
307 |
321 |
435 |
|
高B（mm） |
616 |
528 |
847 |
696 |
738 |
1410 |
|
厚E（mm） |
11+2.35n |
13+2.36n |
13+2.76n |
13+2.75n |
13+2.7n |
22+2.78n |
|
水平接口中心距C |
92 |
174 |
160 |
179 |
188 |
220 |
|
垂直接口中心距D |
519 |
456 |
750 |
567 |
603 |
1190 |
|
重量（kg） |
7.8+0.36n |
7.2+0.52n |
10+0.52n |
12.5+0.72n |
13+0.75n |
31.8+1.73n |
釬焊冷凝器選型表（一）
|
制熱功率（KW) |
制熱功率（HP） |
R22 35℃冷凝 水25-30℃ |
R22 40℃冷凝 水30-35℃ |
水流量t/h |
||||||
|
|
|
|
|
|
|
|
|
|||
|
板換型號 |
板換型號 |
|
||||||||
|
P-26 |
P-50C |
P-95B |
P-200 |
P-26 |
P-50C |
P-95B |
P-200 |
|
|
|
|
2.5 |
1 |
12D |
|
|
|
12D |
|
|
|
0.43 |
|
3.8 |
1.5 |
16D |
|
|
|
16D |
|
|
|
0.6 |
|
5 |
2 |
18D |
|
|
|
20D |
|
|
|
0.86 |
|
7.5 |
3 |
26D |
|
|
|
28D |
|
|
|
1.28 |
|
10 |
4 |
34D |
|
|
|
36D |
|
|
|
1.71 |
|
12.5 |
5 |
42D |
18D |
|
|
46D |
18D |
|
|
2.14 |
|
15 |
6 |
48D |
22D |
|
|
54D |
22D |
|
|
2.58 |
|
17.5 |
7 |
56D |
24D |
|
|
62D |
24D |
|
|
3 |
|
20 |
8 |
64D |
26D |
|
|
|
26D |
|
|
3.43 |
|
22.5 |
9 |
|
28D |
|
|
|
30D |
|
|
3.85 |
|
25 |
10 |
|
30D |
|
|
|
32D |
|
|
4.28 |
|
27.5 |
11 |
|
34D |
|
|
|
36D |
|
|
4.71 |
|
30 |
12 |
|
36D |
|
|
|
38D |
|
|
5.14 |
|
32.5 |
13 |
|
40D |
|
|
|
40D |
|
|
5.57 |
|
35 |
14 |
|
42D |
|
|
|
44D |
|
|
6.01 |
|
37.5 |
15 |
|
46D |
|
|
|
48D |
|
|
6.42 |
|
40 |
16 |
|
48D |
|
|
|
50D |
|
|
6.85 |
|
42.5 |
17 |
|
50D |
|
|
|
52D |
|
|
7.28 |
|
45 |
18 |
|
52D |
|
|
|
56D |
|
|
7.71 |
|
47.5 |
19 |
|
56D |
36D |
|
|
58D |
36D |
|
8.14 |
|
50 |
20 |
|
58D |
38D |
|
|
60D |
38D |
|
8.56 |
|
62.5 |
25 |
|
|
46D |
|
|
|
48D |
|
10.7 |
|
75 |
30 |
|
|
54D |
|
|
|
56D |
|
12.86 |
|
87.5 |
35 |
|
|
62D |
|
|
|
64D |
|
15 |
|
100 |
40 |
|
|
70D |
|
|
|
74D |
|
17.13 |
|
125 |
50 |
|
|
88D |
|
|
|
92D |
|
21.41 |
|
150 |
60 |
|
|
104D |
54D |
|
|
108D |
56D |
25.69 |
|
175 |
70 |
|
|
120D |
62D |
|
|
126D |
66D |
29.97 |
|
200 |
80 |
|
|
138D |
70D |
|
|
144D |
74D |
34.25 |
|
225 |
90 |
|
|
|
78D |
|
|
|
82D |
38.52 |
|
250 |
100 |
|
|
|
88D |
|
|
|
90D |
42.8 |
釬焊冷凝器選型表（二）
|
制熱功率（KW) |
制熱功率（HP） |
R22 50℃冷凝 水40-45℃ |
R22 60℃冷凝 水50-55℃ |
水流量t/h |
||||||
|
|
|
|
|
|
|
|
|
|||
|
板換型號 |
板換型號 |
|
||||||||
|
P-26 |
P-50C |
P-95B |
P-200 |
P-26 |
P-50C |
P-95B |
P-200 |
|
|
|
|
2.5 |
1 |
12D |
|
|
|
14D |
|
|
|
0.43 |
|
3.8 |
1.5 |
18D |
|
|
|
18D |
|
|
|
0.6 |
|
5 |
2 |
22D |
|
|
|
22D |
|
|
|
0.86 |
|
7.5 |
3 |
30D |
|
|
|
32D |
|
|
|
1.28 |
|
10 |
4 |
40D |
|
|
|
42D |
|
|
|
1.71 |
|
12.5 |
5 |
48D |
20D |
|
|
52D |
20D |
|
|
2.14 |
|
15 |
6 |
58D |
24D |
|
|
62D |
24D |
|
|
2.58 |
|
17.5 |
7 |
66D |
26D |
|
|
|
28D |
|
|
3 |
|
20 |
8 |
|
28D |
|
|
|
32D |
|
|
3.43 |
|
22.5 |
9 |
|
32D |
|
|
|
34D |
|
|
3.85 |
|
25 |
10 |
|
36D |
|
|
|
38D |
|
|
4.28 |
|
27.5 |
11 |
|
38D |
|
|
|
42D |
|
|
4.71 |
|
30 |
12 |
|
42D |
|
|
|
46D |
|
|
5.14 |
|
32.5 |
13 |
|
44D |
|
|
|
48D |
|
|
5.57 |
|
35 |
14 |
|
48D |
|
|
|
52D |
|
|
6.01 |
|
37.5 |
15 |
|
50D |
|
|
|
56D |
|
|
6.42 |
|
40 |
16 |
|
54D |
|
|
|
60D |
36D |
|
6.85 |
|
42.5 |
17 |
|
58D |
|
|
|
64D |
38D |
|
7.28 |
|
45 |
18 |
|
60D |
38D |
|
|
66D |
42D |
|
7.71 |
|
47.5 |
19 |
|
64D |
40D |
|
|
|
44D |
|
8.14 |
|
50 |
20 |
|
|
42D |
|
|
|
46D |
|
8.56 |
|
62.5 |
25 |
|
|
52D |
|
|
|
56D |
|
10.7 |
|
75 |
30 |
|
|
60D |
|
|
|
66D |
|
12.86 |
|
87.5 |
35 |
|
|
70D |
|
|
|
76D |
|
15 |
|
100 |
40 |
|
|
80D |
|
|
|
88D |
|
17.13 |
|
125 |
50 |
|
|
100D |
52D |
|
|
108D |
56D |
21.41 |
|
150 |
60 |
|
|
118D |
62D |
|
|
128D |
66D |
25.69 |
|
175 |
70 |
|
|
138D |
70D |
|
|
150D |
78D |
29.97 |
|
200 |
80 |
|
|
156D |
80D |
|
|
|
88D |
34.25 |
|
225 |
90 |
|
|
|
90D |
|
|
|
98D |
38.52 |
|
250 |
100 |
|
|
|
100D |
|
|
|
108D |
42.8 |
釬焊蒸發器選型表（一）
|
制熱功率（KW) |
制熱功率（HP） |
R22 2℃蒸發 水12-7℃ |
R22 3℃蒸發 水12-7℃ |
水流量t/h |
||||||
|
|
|
|
|
|
|
|
|
|||
|
板換型號 |
板換型號 |
|
||||||||
|
P-26 |
P-50D |
P-95A |
P-210 |
P-26 |
P-50D |
P-95A |
P-210 |
|
|
|
|
2.5 |
1 |
16D |
|
|
|
18D |
|
|
|
0.43 |
|
3.8 |
1.5 |
20D |
|
|
|
22D |
|
|
|
0.6 |
|
5 |
2 |
24D |
|
|
|
28D |
|
|
|
0.86 |
|
7.5 |
3 |
34D |
|
|
|
40D |
|
|
|
1.28 |
|
10 |
4 |
44D |
|
|
|
52D |
26D |
|
|
1.71 |
|
12.5 |
5 |
54D |
26D |
|
|
64D |
30D |
|
|
2.14 |
|
15 |
6 |
64D |
30D |
|
|
|
36D |
|
|
2.58 |
|
17.5 |
7 |
|
34D |
|
|
|
40D |
|
|
3 |
|
20 |
8 |
|
38D |
|
|
|
46D |
|
|
3.43 |
|
22.5 |
9 |
|
42D |
|
|
|
50D |
|
|
3.85 |
|
25 |
10 |
|
46D |
|
|
|
56D |
|
|
4.28 |
|
27.5 |
11 |
|
50D |
|
|
|
60D |
36D |
|
4.71 |
|
30 |
12 |
|
56D |
34D |
|
|
66D |
38D |
|
5.14 |
|
32.5 |
13 |
|
60D |
36D |
|
|
|
42D |
|
5.57 |
|
35 |
14 |
|
64D |
40D |
|
|
|
44D |
|
6.01 |
|
37.5 |
15 |
|
|
42D |
|
|
|
48D |
|
6.42 |
|
40 |
16 |
|
|
44D |
|
|
|
50D |
|
6.85 |
|
42.5 |
17 |
|
|
46D |
|
|
|
54D |
|
7.28 |
|
45 |
18 |
|
|
48D |
|
|
|
56D |
|
7.71 |
|
47.5 |
19 |
|
|
52D |
|
|
|
60D |
|
8.14 |
|
50 |
20 |
|
|
54D |
|
|
|
62D |
|
8.56 |
|
62.5 |
25 |
|
|
66D |
|
|
|
78D |
|
10.7 |
|
75 |
30 |
|
|
80D |
|
|
|
94D |
|
12.86 |
|
87.5 |
35 |
|
|
94D |
|
|
|
110D |
60D |
15 |
|
100 |
40 |
|
|
108D |
58D |
|
|
124D |
68D |
17.13 |
|
125 |
50 |
|
|
134D |
70D |
|
|
158D |
82D |
21.41 |
|
150 |
60 |
|
|
162D |
84D |
|
|
194D |
100D |
25.69 |
|
175 |
70 |
|
|
190D |
98D |
|
|
|
116D |
29.97 |
|
200 |
80 |
|
|
220D |
112D |
|
|
|
134D |
34.25 |
|
225 |
90 |
|
|
|
126D |
|
|
|
152D |
38.52 |
|
250 |
100 |
|
|
|
140D |
|
|
|
168D |
42.8 |
釬焊蒸發器選型表（二）
|
制熱功率（KW) |
制熱功率（HP） |
R22 5℃蒸發 水15-10℃ |
R22 10℃蒸發 水20-15℃ |
水流量t/h |
||||||
|
|
|
|
|
|
|
|
|
|||
|
板換型號 |
板換型號 |
|
||||||||
|
P-26 |
P-50D |
P-95A |
P-210 |
P-26 |
P-50D |
P-95A |
P-210 |
|
|
|
|
2.5 |
1 |
14D |
|
|
|
14D |
|
|
|
0.43 |
|
3.8 |
1.5 |
18D |
|
|
|
18D |
|
|
|
0.6 |
|
5 |
2 |
24D |
|
|
|
24D |
|
|
|
0.86 |
|
7.5 |
3 |
34D |
|
|
|
32D |
|
|
|
1.28 |
|
10 |
4 |
42D |
|
|
|
40D |
|
|
|
1.71 |
|
12.5 |
5 |
52D |
26D |
|
|
50D |
24D |
|
|
2.14 |
|
15 |
6 |
62D |
30D |
|
|
58D |
28D |
|
|
2.58 |
|
17.5 |
7 |
|
34D |
|
|
|
32D |
|
|
3 |
|
20 |
8 |
|
38D |
|
|
|
36D |
|
|
3.43 |
|
22.5 |
9 |
|
42D |
|
|
|
38D |
|
|
3.85 |
|
25 |
10 |
|
44D |
|
|
|
42D |
|
|
4.28 |
|
27.5 |
11 |
|
50D |
|
|
|
46D |
|
|
4.71 |
|
30 |
12 |
|
52D |
34D |
|
|
50D |
30D |
|
5.14 |
|
32.5 |
13 |
|
58D |
36D |
|
|
54D |
32D |
|
5.57 |
|
35 |
14 |
|
62D |
38D |
|
|
58D |
36D |
|
6.01 |
|
37.5 |
15 |
|
|
40D |
|
|
62D |
38D |
|
6.42 |
|
40 |
16 |
|
|
44D |
|
|
|
40D |
|
6.85 |
|
42.5 |
17 |
|
|
46D |
|
|
|
42D |
|
7.28 |
|
45 |
18 |
|
|
48D |
|
|
|
44D |
|
7.71 |
|
47.5 |
19 |
|
|
50D |
|
|
|
46D |
|
8.14 |
|
50 |
20 |
|
|
54D |
|
|
|
48D |
|
8.56 |
|
62.5 |
25 |
|
|
64D |
|
|
|
60D |
|
10.7 |
|
75 |
30 |
|
|
76D |
|
|
|
72D |
|
12.86 |
|
87.5 |
35 |
|
|
88D |
|
|
|
82D |
|
15 |
|
100 |
40 |
|
|
100D |
56D |
|
|
96D |
52D |
17.13 |
|
125 |
50 |
|
|
126D |
68D |
|
|
118D |
64D |
21.41 |
|
150 |
60 |
|
|
154D |
80D |
|
|
144D |
76D |
25.69 |
|
175 |
70 |
|
|
184D |
94D |
|
|
170D |
88D |
29.97 |
|
200 |
80 |
|
|
214D |
106D |
|
|
198D |
100D |
34.25 |
|
225 |
90 |
|
|
|
122D |
|
|
|
114D |
38.52 |
|
250 |
100 |
|
|
|
134D |
|
|
|
128D |
42.8 |
